The Planet IGS-501T is a slim line 5 port Gigabit switch that can be wall or DIN rail mounted and features Auto MDI/MDI-X function and an IP30 case (Read more)
The Planet IGS-501T is slim line a 5 port industrial Gigabit
ethernet switch that consists of 5 10/100/1000Mbps auto negotiation
ports. It is housed in a robust IP30 rated metal case making it
ideal for industrial environments and can be wall or DIN rail
mounted.
The IGS-501T offers a high level of protection against
electromagnetic interference and heavy electrical surges which are
usually found on plant floors and is capable operating in
temperatures ranging from -40° to 75°.
The simple plug and play design features auto negotiation
that detects the optimal speed for Cat5, Cat5e and cat 6 cables and
the auto MDI/MDI-X function detects the type of connection to
any ethernet device without requiring special straight-through or
crossover cables.
The IGS-501T possesses an integrated power supply source with
voltages from 12V to 48V DC.
Features:
5-port 10/100/1000Base-T RJ-45 with auto MDI/MDI-X
function
Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE
802.3ab 1000Base-T Ethernet standard
Supports auto-negotiation and 10/100Mbps half / full duplex and
1000Mbps full duplex mode
High performance Store and Forward architecture, broadcast
storm control and runt/CRC filtering eliminate erroneous packets to
optimize the network bandwidth
Prevents packet loss with back pressure (half-duplex) and IEEE
802.3x pause frame flow control (full-duplex)
Backplane (switching fabric): 10Gbps
Integrated address look-up engine, supporting 2K absolute MAC
addresses
1M bits on-chip buffer memory
9K Jumbo packet size support
Automatic address learning and address aging
CSMA/CD Protocol
IP30 metal case
DIN rail and wall-mount design
12 to 48V DC, redundant power with polarity reverse protect
function and connective, removable terminal block for master and
slave power; 24V AC power support
Supports EFT protection 6000V DC for power line
Supports 6000V DC Ethernet ESD protection
-40 to 75 degrees C operating temperature
YOU MIGHT ALSO NEED
Loading
Loading
Loading
Loading
Loading
Loading
SPECIFICATIONS
Hardware
Specifications
Hardware Version
4
Copper Ports
5 x 10/100/1000Base-T RJ45 TP
auto-MDI/MDI-X, auto-negotiation
Connector
Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power
2
Alarm
Provides one relay output for power
failure
Alarm relay current carry ability: 1A @ DC 24V
LED
3 x LED for system and power:
Green: DC Power 1
Green: DC Power 2
Green: Power Fault
2 x LED for each copper port
Green: 1000Mbps LNK/ACT
Orange:10/100Mbps LNK/ACT
ESD Protection
6KV
EFT Protection
6KV
Power Requirements
12~48V DC, Redundant power with polarity reverse protection
function, 24V AC power support
Power Consumption / Dissipation
5.28 watts/18BTU
Installation
DIN rail kit and wall-mount ear
Enclosure
IP30 metal case
Dimensions (W x D x H)
32 x 87 x 135 mm
Weight
456g
Switch
Specifications
Switch Processing Scheme
Store-and-Forward
Address Table
2K entries
Buffer Memory
1M bits on-chip buffer memory
Flow Control
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.1p Class of Service
